Piezoelectric Ceramic for Ultrasonic Atomizing






  Widely used in:
      * Air humidifier
      * Floral decoration
      * Fountains
      * Medical application
      * Aquatic design
      * Stage design

  Piezoelectric atomizing transducer
Electrode: Nickel
Film: Nickel
  Spec Dimension
(mm)		 Frequency
(MHz)		 Capacitance
(pf)		 Impedance
(Ω)		 Fog output
(ml/h)		 Life
(hour)
  ANN-1617N Φ16 x 1.25 1.7MHz±50KHz 1200±20% ≤1.5 250 5000
  ANN-2017N Φ20 x 1.25 1.7MHz±50KHz 1900±20% ≤2.0 350 5000
  ANN-2517N Φ25x 1.25 1.7MHz±70KHz 2100±20% ≤2.0 400 5000
  ANN-2524N Φ25x 0.89 2.4MHz±70KHz 2300±20% ≤2.0 450 5000

  Piezoelectric atomizing transducer
Electrode: Nickel
Film: Titanium
  Spec Dimension
(mm)		 Frequency
(MHz)		 Capacitance
(pf)		 Impedance
(Ω)		 Fog output
(ml/h)		 Life
(hour)
  ANN-1617T Φ16 x 1.25 1.7MHz±50KHz 1200±20% ≤1.5 250 5000
  ANN-2017T Φ20 x 1.25 1.7MHz±50KHz 1900±20% ≤2.0 350 5000
  ANN-2517T Φ25x 1.25 1.7MHz±70KHz 2100±20% ≤2.0 400 5000
  ANN-2524T Φ25x 0.89 2.4MHz±70KHz 2300±20% ≤2.0 450 5000





  Piezoelectric atomizing transducer
Electrode: Nickel
Film: Glaze
Special: used in acid liquid
  Spec Dimension
(mm)		 Frequency
(MHz)		 Capacitance
(pf)		 Impedance
(Ω)		 Fog output
(ml/h)		 Life
(hour)
  ANN-1617G Φ16 x 1.25 1.7MHz±50KHz 1200±20% ≤1.5 250 5000
  ANN-2017G Φ20 x 1.25 1.7MHz±50KHz 1900±20% ≤2.0 350 5000
  ANN-2517G Φ25x 1.25 1.7MHz±70KHz 2100±20% ≤2.0 400 5000
  ANN-2524G Φ25x 0.89 2.4MHz±70KHz 2300±20% ≤2.0 450 5000



Piezoelectric atomizing transducer
Film: Sheet metal
Special: used in perfume atomizing
  Spec Piezo ceramic
Dimension
(mm)		 Sheet metal
Dimension(mm)		 Frequency
(KHz)		 Capacitance
(nF)		 Drive voltage
  ANN-XSWH-14501 Φ9.6xΦ4.6x0.5 Φ6.4x0.05 145±5 2100±20% 1.5V
